Product No：Sunhotion-RNP0521-NGSL
Input Voltage:AC85-265V
Ouput Voltage:DC9-25V
Type Current:80-150mA
Dimension(L*W*H:30.5X11X14mm
Certified:RoHS
Connector: 2 leads
Circuit type: isolated circuit
Weight：5g
Product features: Ⅰ led candle lamp power supply, compact design, Ⅱ input with fuse, safe no-load protection device, Ⅲ output overload protection, Ⅳ output short circuit protection, Ⅴ over temperature protection function, Ⅵ suitable for LED candle lamp, bulb lamp, spotlight and lamp cup
|
Product No |
AC Input Range（Vac |
Max. Pout（W） |
Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（mA） | THDPF(Typ.) | PF(Typ.) |
Eff.(Typ.) |
| Sunhotion-RNP0521-NGS | 85-265 | 5 | 9-25 | 9-23 | 80-150 | 12% | 0.65 | 76% |
