I Compact Design II safety load-free protection device III output overload protection IV output short circuit protection V over-temperature protection function VI. PFC>0.95 Ⅶ conform to EMC, safety regulations requirements VIII economical and convenient installation □ input and output welding wire terminals and welding connecting wires are convenient and optional □ applicable to LED ceiling lamp, downlight, ceiling lamp, panel lamp and floodlight
|
Product No
|
AC Input Range（Vac）
|
Max. Pout（W）
|
Vout Range（Vdc）
|
Full Power Vout Range（Vdc）
|
Iout（mA）
|
THD
|
PFC
|
Eff
|
|
SC-050WE1250
|
85-265
|
50
|
24-42
|
24-42
|
1250
|
20%
|
0.95
|
88%
|
SC-050WE1150
|
85-265
|
46
|
24-42
|
24-42
|
1150
|
20%
|
0.95
|
88%
|
SC-050WE0950
|
85-265
|
40
|
24-42
|
24-42
|
950
|
20%
|
0.95
|
88%
|
