Ⅰ applicable to common thyristor dimmer, front and rear tangential LED dimming Ⅱ meeting the requirements of EMC and safety regulations Ⅲ isolated power supply Ⅳ safe no-load protection device Ⅴ output overload protection Ⅵ output short circuit protection Ⅶ over temperature protection function Ⅷ economical and convenient installation Ⅷ output with terminal or public bus optional IX dimming range 1... 100% Ⅹ applicable to LED ceiling lamp, downlight, ceiling lamp, panel lamp and projection lamp
|
型号
|
输入电压范围（Vac）
|
最大输出功率（W）
|
输出电压范围（Vdc）
|
推荐工作电压范围（Vdc）
|
输出电流范围（mA）
|
总谐波失真
|
功率因数
|
效率
|
|
SC-TW30HM
|
200-240
|
24
|
27-40
|
27-40
|
600
|
|
|
|
SC-TW30LM
|
100-120
|
24
|
27-40
|
27-40
|
600
|
|
|
|
SC-TW24HM
|
200-240
|
24
|
18-25
|
18-25
|
700
|
|
|
|
SC-TW24LM
|
100-120
|
24
|
18-25
|
18-25
|
700
|
|
|
|
