Product model: sn-rgb10
Input voltage: AC85-265V
Output voltage: dc6-12v
Typical current: 100-280ma
Dimension (L * w * h): 60 * 38 * 24mm
Connector: 6 leads
Circuit type: isolated circuit
Weight: 88g
|
Product No |
AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） |
Full Power Vout Range |
IoutmA） |
THD(Typ.) |
PF(Typ.) |
Eff.(Typ.) |
| SN-RGB10 | 85-265 | 4 | R: 6-12 | 6-12 | 280 | 20% | 0.65 | 65% |
| 4 |
G:6-12 |
6-12 |
280 |
|
|
|||
| 4 |
B:6-12 |
6-12 |
280 |
|
